Sliding winches will move easily in both directions to position on the track and then lock into place when tension is applied to the webbing. Sliding winches must be used with Kinedyne winch track (part numbers 3606, 3606-12 and 3607).

Specifications: A: 7.68" B: 4.88" C: 7.72" D: 3.94"

Working Load Limit: 5,500 lbs./2500 kgs.

Weight: 10.1 lbs., 4.6 kgs.

Sliding winches will move easily in both directions to position on the track and then lock into place when tension is applied to the webbing. Sliding winches must be used with Kinedyne winch track (part numbers 3606, 3606-12 and 3607).

Specifications: A: 7.68" B: 4.88" C: 7.72" D: 3.94"

Working Load Limit: 5,500 lbs./2500 kgs.

Weight: 10.1 lbs., 4.6 kgs.

Double duty combination winches are designed to be used with webbing or wire cable.

Specifications: A: 9.27" B: 6.50" C: 4.33" D: 3.94"

Cable Working Load Limit: 3,335 lbs./1515 kgs.

Webbing Working Load Limit: 5,500 lbs./2500 kgs.

Weight: 16.0 lbs., 7.3 kgs.

Portable winches allow flexibility of winch placement along the trailer side channel.

Specifications: A: 7.75" B: 4.88" C: 4.38" D: 4.00"

Working Load Limit: 5,500 lbs./2500 kgs.

These sliding winches and track combinations provide an efficient and flexible securement system. The winch moves easily in both directions, but locks firmly in place when tension is applied. U.S. Patent Number 5,853,164

Specifications: A: 7.71" B: 4.88" C: 5.24" D: 3.94"

Working Load Limit: 5,500 lbs./2500 kgs.

Weight: 8.4 lbs., 3.8 kgs.

Weld-on winches are designed to be permanently mounted in a fixed position.

Specifications: A: 7.68" B: 4.88" C: 4.33" D: 3.94"

Weight: 8.1 lbs., 3.7 kgs.

Weld-on winches are designed to be permanently mounted in a fixed position.

Specifications: A: 7.68" B: 4.88" C: 4.33" D: 3.94"

Working Load Limit: 5,500 lbs./2500 kgs.

Weight: 8.1 lbs., 3.7 kgs.

Ratcheting Sliding Winch for Webbing Bottom Mount Style.
7-mm. heat-treated steel components for light weight and increased strength
Efficient ratcheting design for ease of use and quicker tensioning
Sliding configuration for Ancra track 
Working load limit: 5,500 lbs

Ratchet winch for Flatbed Trailers Storable Slider for C Track
7-mm. heat-treated steel components for light weight and increased strength
Efficient ratcheting design for ease of use and quicker tensioning
Increased space behind the mandrel for storage capability with sliding configuration 
Working load limit: 6,000 lbs

Double L Flat Hook Receiver. For 3608 Track.

Specifcations: A: 6.25" B: 5.00" C: 5.25" D: 4.00"

Weight: 7.5 lbs., 3.4kgs.

Flat Hook Receiver

Specifications: A: 6.25" B: 5.00" C: 6.25" D: 4.00"

Weight: 6.0 lbs., 2.7 kgs.

Sliding winches will move easily in both directions to position on the track and then lock into place when tension is applied to the webbing. Sliding winches must be used with Kinedyne winch track (Part Numbers 3606 and 3607). All sliding winches can also be welded in place for fixed application.

Specifications: A: 7.75" B: 4.88" C: 6.50" D: 3.94"

Working Load Limit: 5,500 lbs./2500 kgs.


Weight: 10.3 lbs., 4.7 kgs.
